Designed to replace Suburban and Atwood/HydroFlame Fan Control boards as well as maintain backward compatibility with the Fan 50 Plus, and UIB Fan Control boards. This board can also be used to upgrade older furnaces to add the Fan Control feature.
More Information
Item #
51464
Brand
Dinosaur Electronics
Model
FAN50PLUSPINS
Fits
Furnaces with Suburban's and Hydro Flame's fan control feature, and can also be used to implement the fan control feature in most 12V DC DSI furnaces. *Not recommended for use in the Duo-Therm 900 series furnaces where the thermostat is in the ground circuit.
Features
Jumper selectable operation
12 VDC operation
Works in 12 VDC furnaces* (See Fits)
Microcontrolled
Diagnostic LED
With this board installed in your furnace, the fan will no longer run all night blowing cold air. Board knows when the propane has run out or if the furnace did not light, and shuts the fan off one minute after the third try. It has the same great design features as the other Universal Ignitor Boards, but with an added fan control relay.
The basic purpose of a Fan Control Ignitor Board is to shut the fan motor off if the board fails to sense a flame after
the third ignition try. Thus, battery drain is reduced and the needless blowing of cold air is eliminated.
The FAN 50 Plus Pins , after shutting the fan motor off, will wait for 1 hour and repeat the whole sequence again before
permanent shut down.
