WFCO Brown 35 Amp Distribution Panel Converter
WF-8735 model converters provide 35A DC output, and a highly reliable nominal 13.6V DC with or without a battery. No extra filtering is required.
- Item #
- 69094
- Color
- Brown
- Special Order Item
- No
- Ships LTL Freight
- No
Description / WFCO Brown 35 Amp Distribution Panel Converter
WFCO’s three-stage battery charging results in longer battery life and is totally automatic. Nominal voltage output modes are a 13.2V DC range “float” mode, 13.6V DC range “absorption” charge mode, and a 14.4V DC range “bulk” charge mode. Short-circuit and reverse polarity protection provide you with further reliability and peace of mind. The cooling fan for the WF-8735 operates only when needed and ensures quiet operation. Front-cooled fan installation does not create additional installation space requirements.
Every model is designed to comply FCC Class B, which means that the converters do not cause interference with televisions, radios or other signals. The 8735 model also brings you the convenience of built-in AC/DC distribution. 30-amp main AC breaker and a total of up to five 20-amp branch AC circuits can be installed. Six DC branch circuits include LED bulbs that illuminate to indicate open circuits.
*Power center does NOT include individual fuses or breakers.
Every model is designed to comply FCC Class B, which means that the converters do not cause interference with televisions, radios or other signals. The 8735 model also brings you the convenience of built-in AC/DC distribution. 30-amp main AC breaker and a total of up to five 20-amp branch AC circuits can be installed. Six DC branch circuits include LED bulbs that illuminate to indicate open circuits.
*Power center does NOT include individual fuses or breakers.
More Information
| Item # | 69094 |
|---|---|
| Brand | WFCO |
| Series | 8700 |
| Model | WF-8735-PB |
| Replaces | WF-8735-P |
| Style | Distribution Panel |
| Input | 105-130 VAC, 60 Hz |
| Output Amperage | 35 Amps (Output Power: 600 W) |
| Color | Brown |
| Features | Converter Type: Three-Stage Converter Charger Voltage Output: 13.2 – 14.4V DC Range Absorption Mode (Nominal Voltage): 13.6V DC (nominal voltage) Bulk Mode (Quick Charging Voltage): 14.4V DC (quick charging voltage) Float Mode (Trickle Charge Voltage): 13.2V DC (trickle charge voltage) AC Circuits (twin breakers): 6 (Main and 5 branch circuits) DC Circuits (Quantity): 6 (one battery circuit) Case Material: Plastic Over Current : Yes Over Temperature: Yes Over Voltage : Yes Reverse Polarity: Yes Cooling System: Yes Certifications : FCC |
| Included | *Power center does NOT include individual fuses or breakers. |
| Dimensions | Length: 3-3/4 Inch Width: 11-7/8 Inch Height: 7-5/16 Inch |
| Warranty | 2 Year |
| Net Weight | 5.5 |
| Special Order Item | No |
